C0K510418, Norgren Pneufit C Series Threaded In-line Regulator, Push In 4mm Tube Inlet Port x G 1/8 Outlet Port x Push In 4mm Tube

IMI Norgren In-Line Regulator, NBR Seals, 10 Bar Maximum Operating Pressure - PNEUFIT C Series - C0K510418

Control the movement of compressed air around your pneumatic system with this in-line regulator from IMI Norgren. It's a banjo-type that maintains the pressure level in your equipment at a specific range to make sure there are no peaks or troughs. The fitting's nickel-plated brass body resists corrosion and impact, so it stands the test of time in demanding conditions. NBR seals keep external contaminants at arm's length and prevent leaks, prolonging your equipment's lifespan. An operating pressure range between -0.9 and 10 bar makes this a suitable option for both light-duty and heavy-duty applications.

Features & Benefits

• Performs reliably in an operating temperature range of 0°C to +60°C
• G1/8 thread size for straightforward coupling with standard equipment
• Light weight of 20g minimises strain on your pipework
• Compact dimensions of 30.5 (L) x 40 (W) x 16mm (H), so it fits easily into tight setups

Applications

• Water treatment plants
• Medical devices
• Agricultural equipment

How do I fit pipes to the inlet and outlet?

Both the inlet and outlet are push-in fittings, so no tools are needed. You just push a tube through the collet and O-ring until it hits the stop, then pull back gently to feel it engage.

Datasheet - C0K510418
