Renesas Electronics 5T9306NLGI, Clock Buffer LVDS, 1-Input, 8-Pin SOIC

The Renesas Electronics IDT5T9306 2.5V differential clock buffer is a user-selectable differential input to six LVDS outputs. The fanout from a differential input to six LVDS outputs reduces loading on the preceding driver and provides an efficient clock distribution network. The IDT5T9306 can act as a translator from a differential HSTL, eHSTL, LVEPECL (2.5V), LVPECL (3.3V), CML, or LVDS input to LVDS outputs. A single-ended 3.3V / 2.5V LVTTL input can also be used to translate to LVDS outputs.

Guaranteed Low Skew < 40ps (max)
Very low duty cycle distortion < 125ps (max)
High speed propagation delay < 1.75ns (max)
Additive phase jitter, RMS 0.159ps (typical) @ 125MHz
Up to 1GHz operation
Selectable inputs
Hot insertable and over-voltage tolerant inputs
3.3V / 2.5V LVTTL, HSTL, eHSTL, LVEPECL (2.5V), LVPECL
(3.3V), CML, or LVDS input interface
Selectable differential inputs to six LVDS outputs
Power-down mode
2.5V VDD
Available in VFQFPN package

Datasheet - 5T9306NLGI
