SKF GE 10 C 10mm Bore Spherical Bearing, 21600N Axial Load Rating, 19mm O.D

SKF Spherical Bearing, Cylindrical Bore, Unsealed, 10mm ID, 19mm OD - GE 10 C

Looking for a spherical bearing to handle shaft deflection? Choose this unit from SKF. The mouldings in between its steel inner and outer rings create a curved sliding surface that's maintenance-free and allows for angular rotation. As indicated by its basic dynamic load rating, the bearing is capable of enduring up to 8.65kN in a constant direction for 1,000,000 revolutions, so you can be sure it's robust and reliable. For versatility, it's designed to withstand loads in the radial and combined radial and axial directions.

Features & Benefits

• Comes with dry lubricant to avoid the need for regreasing
• PTFE sintered bronze sliding material is hard and strong for increased durability
• Steel bearing material resists corrosion to withstand the demands of damp conditions

Applications

• Vehicle engines
• Car suspension systems
• Robotics systems
• Sewing machines

How much does this bearing weigh?

This bearing has a low weight of 12g to avoid putting strain on your system.

What's the static load rating of this unit?

This spherical bearing has a static load rating of 21.6kN, so it's protected against shocks and vibrations when stationary or moving at slower turning speeds.
