Renesas Electronics 9DBL0452BKILF, LVDS Buffer 8 TTL Buffer, 48-Pin VFQFPN

The Renesas Electronics 9DBL0452 4-output zero-delay/fan-out buffer is a 3.3V member of Renesas' Full-Featured PCIe family. The 9DBL0452 supports PCIe Gen1 through Gen5 and both Common and Independent Reference Clock architectures.

Additive PCIe Gen5 CC jitter < 60fs RMS (fan-out mode)
PCIe Gen5 CC jitter < 150fs RMS (High-BW ZDB Mode)
4 Low-Power HCSL (LP-HCSL) outputs eliminate 4 resistors per output pair
Direct connection to 85Ω transmission lines
Dedicated OE# pin for each output
Spread Spectrum tolerant
Pin or SMBus configuration
3 selectable SMBus addresses
SMBus interface not required for device operation

Datasheet - 9DBL0452BKILF
