1492-SPM3D060-N, Rockwell Automation 1492-SP 1492-SPM MCB, 3P, 6A Curve D

Rockwell Automation MCB, 6A Current Rating, Type D - 1492-SPM3D060-N

Safeguard your electrical equipment with this MCB from Rockwell Automation. It's a safety device that automatically trips and turns a circuit off when a current overload or fault occurs. Shock and vibration resistance prevents false tripping, so there's minimal downtime in your systems. An LED indicator shows the unit's operation status by signalling red when on and green when off, for easy monitoring. Type D characteristics indicate that the breaker trips when the supply current is 10 to 20 times the full load current of the circuit, meaning it's a slow-acting option that can handle the initial inrush currents you get when starting motors or lighting rigs.

• Screw terminals for easy attachment to equipment with a Polzdriv 2 screwdriver
• Mechanical life of 20,000 operations for long-term use
• Broad operating temperature range between -25ºc and +55ºC for use in harsh conditions
• Low weight of 115g, so it's easy to handle during installation
• Current rating of 6A for energy efficiency and use in high-voltage applications

Standards and Certifications

• IEC
• CSA
• UL

The Rockwell Automation Automation 1492-SPM supplementary protector is a 3+N pole thermal magnetic circuit breaker which provides an overcurrent protection for equipment where branch circuit protection is already provided, or is not required. It has 6 amperes continuous current rating and trip curve D.

What's the withstand voltage of this MCB?

Current limiting
Fast breaking time
Superior shock and vibration resistance to prevent nuisance tripping
RoHS compliant and fully-recyclable device
Suitable for extreme ambient conditions

This MCB has a rated surge voltage of 4kV, so it protects your equipment against damage from sudden current spikes and faults.

Datasheet-1492-SPM3D060-N
