STMicroelectronics 1200V 10A, Rectifier & Schottky Diode, 2-Pin D2PAK HV STPSC10H12G2-TR

The STMicroelectronics 10 A, 1200 V Sic diode is an ultra-high performance power Schottky diode. It is manufactured using a silicon carbide substrate. The wide band gap material allows the design of a Schottky diode structure with a 1200 V rating. Due to the Schottky construction, no recovery is shown at turn-off and ringing patterns are negligible. The minimal capacitive turn-off behaviour is independent of temperature. Housed in D2PAK HV, this diode is perfectly suited for a usage in PFC applications, in OBC, DC/DC for EV, easing the compliance to IEC-60664-1. The STPSC10H12G2-TR will boost performances in hard switching conditions. Its high forward surge capability ensures good robustness during transient phases.

No or negligible reverse recovery
Switching behaviour independent of temperature
Robust high voltage periphery
Operating Tj from -40 °C to 175 °C
Low VF
D²PAK HV creepage distance (anode to cathode) = 5.38 mm min.
ECOPACK2 compliant

Datasheet - STPSC10H12G2-TR
