STMicroelectronics 1200V 10A, Rectifier & Schottky Diode, 2-Pin D2PAK HV STPSC10H12G2Y-TR

The STMicroelectronics 10 A, 1200 V Sic diode is an ultra-high performance power Schottky diode. It is manufactured using a silicon carbide substrate. The wide band gap material allows the design of a Schottky diode structure with a 1200 V rating. Due to the Schottky construction, no recovery is shown at turn-off and ringing patterns are negligible. The minimal capacitive turn-off behaviour is independent of temperature. Housed in D2PAK HV, this diode is perfectly suited for a usage in PFC applications, in OBC, DC/DC for EV, easing the compliance to IEC-60664-1. The STPSC10H12G2Y-TR will boost performances in hard switching conditions. Its high forward surge capability ensures good robustness during transient phases.

AEC-Q101 qualified
No or negligible reverse recovery
Switching behaviour independent of temperature
Robust high voltage periphery
PPAP capable
Operating Tj from -40 °C to 175 °C
Low VF

Datasheet - STPSC10H12G2Y-TR
