1492-J3DF, Rockwell Automation 1492-J3 Series Pluggable Terminal Block, 2-Way, 20A, 26 - 12 AWG Wire, Plug In Termination

Rockwell Automation IEC 1492-J3DF Screw Type Single Circuit Pluggable Terminal Block

Experience easy installation, improved safety, and enhanced durability with the 1492-J Screw Type Single Circuit Diode Forward Terminal Block with Test Plug Sockets by Rockwell Automation. This family of terminal blocks adheres to recognised international IEC standards, offering high quality and reliable solutions for your control cabinet.

This terminal block is DIN rail mountable for seamless installation and organisation into your wiring system. It features a secure self-locking screw type clamp design with steel clamps and screws. Risk of electric shock is reduced due to its IP2X finger-safe housing.

The 1492-J3DF is a single-level diode forward feed-through terminal block with test plug sockets on both sides, in black.

Maximum wire size and rating:

UL: 26-12 AWG (10A @300V AC/DC)
CSA: 26-12 AWG (1A @300V AC/DC)
IEC:2.5mm² (14A @500V AC/DC)

Features and Benefits:

• Self-locking screw-type clamp design
• Improved panel space use
• DIN rail mountable
• Backed-out screws
• Wide range of accessories available
• The 1492 family adheres to recognised international IEC, UL, CSA and ATEX standards

Rockwell Automation Standard Terminal Blocks offer a classic solution for wiring connection and highly efficient distribution of power. They are leading the industry in providing a wide range of products with Short Circuit Current Ratings (SCCRs), such as terminal blocks, power blocks, circuit breakers, contactors, disconnects, and drives.

What is a terminal block?

A terminal block is a modular component which secures two or more wires together inside an insulated frame. This keeps wiring safely and neatly organised, protecting other components in the circuit and minimising risk of electric shock to people working on or near them. They can be easily connected or disconnected within the block which provides easy troubleshooting and maintenance. They can feature different termination types, such as screw, spring-clamp, and push-in. They are used in a wide range of industrial, commercial, and domestic applications and are known to be a space-saving, cost-effective type of connector.
