2CSR256040R1324 DS203NC C32 AC30, ABB RCBO, 32A Current Rating, 4P Poles, 30mA Trip Sensitivity, Type C

ABB 4-Pole RCBO, 32A Current Rating, 400 to 415 V AC Voltage Rating - DS203NC Series - 2CSR256040R1324 DS203NC C32 AC30

Fully protect your electric networks and devices with this 4-pole RCBO from ABB. It combines the functions of a miniature circuit breaker and residual current device to safeguard against overloads and short-circuits. It also offers protection against sinusoidal alternating earth fault currents and indirect contacts, while providing additional shielding against direct contacts. As it mounts on a DIN rail, installing the device is quick and simple. Use the test button to perform functional checks and make sure the unit's working properly.

Features & Benefits

• Wide operating temperature range from -25°C to 55°C for use in tough environments
• Rugged plastic housing insulates live wires and contacts for added safety
• Contact position indication tab shows when the component is on or off

Applications

• Manufacturing applications
• HVAC systems
• Data and telecommunications equipment

Can an RCBO replace an RCD on a distribution board?

Yes, as an RCBO does the jobs of a residual current device and MCB, you can install it in place of an RCD. You can even use it as a mains switch on your distribution board.
