RS PRO Brushed DC Motor, 200 W, 37.5 V, 64 Ncm, 3000 rpm, 10mm Shaft Diameter, Двигатель

Low Profile dc Motors

Powerful, low profile motors offer many benefits when compared to a conventional permanent magnet dc motor.

Low profile construction requires less space than a conventional motor
Long motor life even when operated at full rating
High power to weight ratio
Very smooth running at slow speeds
Fast acceleration from rest under full load conditions
Low inductance
Low brush sparking
Low r.f.i. emissions
Available in two magnet materials:

M Style uses ferrite magnet material
N Style uses rare earth magnet material

N Style provides up to 2 1/2 times power, three times higher torque, from the same size motor compared with M type

RS PRO Brushed DC Motor, 200 W, 37.5 V dc, 64 Ncm, 3000 rpm, 10 mm Shaft Diameter

With its ultra-slim profile, this RS PRO brushed DC motor can fit in compact spaces with minimal effort. It has a high power-to-weight ratio, so it delivers full power despite its low-profile build – all while ensuring low levels of radio-frequency interference.

The circuits of this brushed DC motor are protected against malfunctions caused by radio-frequency interference so can perform reliably. The motor also has an ultra-low speed capability, very low inertia and low inductance to avoid energy dispersion and conserve power.

This product has been stringently tested and meets RoHS standards, so you won't need to worry about hazardous substances. Zero cogging and minimal torque ripple results in reduced vibrations and noise, giving you a long-lasting and reliable machine. It's commonly used in industrial applications including automation processes, automotive equipment and the oil and gas industries.

Features and Benefits

• Supply voltage of 37.5 V DC
• Brushed DC motor type
• Power rating of 200 W
• Current rating of 7.3 A
• Output speed of 3000 rpm
• Maximum output torque of 64 Ncm
• Length of 60 mm
• Shaft diameter of 152 mm
• RoHS compliant

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

RS Pro Datasheet
