ERM8-013-01-S-D-RA-DS-L-K-TR, Samtec ERM8 Series Vertical PCB Header, 26 Contact(s), 0.8mm Pitch, 2 Row(s), Shrouded

Samtec ERM8 Vertical PCB Header, 26 Contact, 0.8mm Pitch - ERM8-013-01-S-D-RA-DS-L-K-TR

This is a right-angled board-mount header designed for use in high-speed systems. It operates on a 0.80 mm Edge Rate® contact system, specifically engineered for applications requiring high-mating cycles and 56Gbps PAM4 performance. This connector mates with ERF8 board-mounted sockets, providing exceptional durability and reliable signal transmission. Whether you need board-to-board, cable-to-board, or cable-to-cable solutions, the ERM8-013-01-S-D-RA-DS-L-K-TR offers flexibility for your design needs.

Features & Benefits

• The Edge Rate® contact system ensures reliable signal integrity at 56Gbps PAM4
• Engineered for applications with high-mating cycles, providing long-lasting performance
• Space-saving right-angle configuration is ideal for designs with limited board space
• Its rugged construction makes it suitable for demanding environments

Applications

• Used for high-speed connections within server racks
• Ensures efficient signal transmission in network infrastructure
• Provides reliable connectivity for control systems and machinery
• Suitable for automotive applications requiring high-speed data transfer

What is the contact pitch of the ERM8-013-01-S-D-RA-DS-L-K-TR?

The ERM8-013-01-S-D-RA-DS-L-K-TR operates on a 0.80 mm Edge Rate® contact pitch.

Can I use this connector for high-speed data transmission?

Yes, the ERM8-013-01-S-D-RA-DS-L-K-TR is designed for 56Gbps PAM4 performance.
