239173 FAZ6-C16/3N, Eaton xEffect MCB, 3P+N, 16A Curve C, 415V AC, 10 kA Breaking Capacity

Eaton MCB, IP20 Rating, DIN Rail Mounting - xEffect FAZ6 Series - 239173 FAZ6-C16/3N

Don't get caught out by current overloads – trust this MCB from Eaton to stop power faults instantly. Type-C tripping characteristics mean the unit shuts down circuits when it receives three to five times the rated current of 16A. It tackles high inrush currents with ease thanks to its breaking capacity of up to 10kA at 230V AC. That makes it a handy tool for taking on high-load tasks like managing commercial lighting systems or firing up industrial motors.

Features & Benefits

• 3P+N configuration means you can protect multiple circuits at once
• Touch-proof IP20 rating indicates it protects against shocks
• Operating temperature range between -25°C and +75°C for compatibility with harsh environments
• LED indicator shows operational status at a glance
• Includes a guide for secure terminal connection

How is this MCB mounted?

This unit snaps right onto a standard 35mm DIN rail for fuss-free mounting. Its three lock-in positions on the DIN rail clip also support removal from the existing busbar.

How much does this breaker weigh?

Weighing in at just 456g, this compact component won't put excess strain on your systems.

Note

Eaton formerly known as Moeller

Datasheet - FAZ6-C16/3N
