101044 DILA-XHIT22, Eaton Auxiliary Contact, 4 Contact, 2 N/O, 2 NC, Front Fixing, 9, 12, 15, DILL, DILM7, MSC-D, MSC-R

Eaton Auxiliary Contact, 4 Poles, 500V Contact Voltage Rating - DILA Series - 101044 DILA-XHIT22

Electrically enhance your motor control devices with this auxiliary contact from Eaton. You can use the multitalented device to add a light, alarm or button, or to control another function at the same time as your motor or machine. It's front fixing to save space and snaps onto MSC-D and MSC-R series motor starters as well as DILL and DILM series contactors, so installation's a breeze. The four poles have a 2NC/2NO configuration, making this a versatile choice for your signalling and control tasks. The opposing contacts are interlocked to prevent them from closing at the same time, giving your system a safety boost.

Features & Benefits

• Finger and back-of-hand proof to help keep you safe during installation
• Electrical lifespan of 1,300,000 operations means it stays the distance
• Works with AC or DC circuits for convenience
• Rated impulse withstand voltage of 6,000V AC to handle power surges

What type of terminals does this auxiliary contact have?

This contact comes with screw terminals to achieve a reliable connection. You'll find labelled contacts on the face to help you make your connections in no time. It accepts solid and stranded wires, with or without a ferrule, giving you plenty of options.

Note

Eaton formerly known as Moeller
