1SDA067417R1 XT1N 160 TMD 125A FF, ABB, SACE Tmax XT MCCB Molded Case Circuit Breaker 3P 125A, Breaking Capacity 36 kA, Fixed Mount

ABB MCCB, Thermomagnetic Release, 15ms Opening Time - XT1N Series - 1SDA067417R1 XT1N 160 TMD 125A FF

To stop electrical damage in its tracks, defend your equipment with this MCCB from ABB. The unit swiftly breaks the power supply in the event of faults like short circuits or overloads. For versatile operation, it's compatible with both AC and DC voltages. On the front, there's a test button you can use for hassle-free troubleshooting to ensure the unit's in good working condition. A current rating of 125A assures you it can safely handle the rigours of your high-power electrical systems.

Features & Benefits

• Opening time of 15ms supports rapid switching
• Toggle switch lets you reset it quickly and easily
• Front terminal connection makes wiring a breeze
• 3-pole design fits 3-phase systems

Applications

• Lighting controls
• Storage facilities
• Commercial buildings
• Energy generation

How durable is this MCCB?

This breaker has a mechanical durability rating of 240 cycles per hour. This means that if needed, it can trip and be reset multiple times a day with minimal risk of damage.

What's the setting range of this MCCB?

This device has a setting range between 87.5 and 125A, letting you adjust the tripping function to match your preferred configuration.
