RS PRO 24 Way Cable Mount D-sub Connector Plug

Looking for a 24-way D-sub plug to link your electronic devices and components? Use this RS PRO cable-mounting connector to establish interfaces between computer units, monitors and other equipment like printed circuit boards (PCBs).
The polybutylene terephthalate (PBT) construction of the housing resists heat buildup to prevent the overheating of equipment and the outbreak of fires to ensure your safety. Chemicals like solvents and cleaning agents won't penetrate the casing so it won't crack or disintegrate and expose your wires and connections to damage. A rubber cable gland supports and lessens strain on the connectors so they don't bend and interrupt the effective transfer of power and signals.
This product is Restriction of Hazardous Substances (RoHS) certified so contains only minimal amounts of any harmful substances. The item is suitable for industrial, medical and military applications.

Features and Benefits

• Straight body orientation
• Brass contact material
• Gold contact plating
• Current rating of 5 A
• Dimensions of 48.6 (length) x 15.3 (width) x 41.4 mm (depth)
• Male gender
• PBT (polybutylene terephthalate) housing material
• Maximum operating temperature of +105°C
• Minimum operating temperature of -55°C
• Cable mounting type
• 24 contacts
• 24 poles
• Centronics series
• Solder termination method
• Solder termination type
