Digilent B200mini XC6SLX75 FPGA RF Transceiver Radio Board for HDSDR 6GHz 6002-410-022

This Digilent product has a wide frequency range from 70 MHz to 6 GHz and a user programmable Xilinx Spartan-6 XC6SLX75 FPGA, this flexible and compact platform is ideal for both hobbyist and OEM applications. The similar Ettus USRP B205mini-i is an industrial temperature version with a larger FPGA for more advanced applications.The RF front end uses the Analog Devices AD9364 RFIC transceiver with 56 MHz of instantaneous bandwidth. The board is bus-powered by a high-speed USB 3.0 connection for streaming data to the host computer. The USRP B200mini also includes connectors for GPIO, JTAG, and synchronization with a 10 MHz clock reference or PPS time reference input signal.

Analog Devices are AD9364 RFIC transceiver
Xilinx Spartan-6 XC6SLX75 FPGA
Channels present are 1 TX, 1 RX
Frequency range is from 70 MHz to 6 GHz
Instantaneous Bandwidth is Up to 56 MHz
IIP3 at typical NF is 20 dBm
Power Output is less than 10 dBm
Receive Noise Figure is greater than 8 dB

Datasheet - 6002-410-022
