1893313, Phoenix Contact 5mm Pitch 4 Way Pluggable Terminal Block, Plug, Through Hole

Phoenix Contact CLASSIC COMBICON MSTBT 5.0mm Terminal Block Plug Connectors

CLASSIC COMBICON MSTB 2,5 5.0mm pitch plug-in cable mount terminal block connectors with a 0.2 to 2.5mm² screw connection
For screwdriver see stock number 390-9641
for insertion bridges see stock numbers 802-0686 and 802-0683 typically
For cable housings see stock number 292-9420 (3 way) and 292-9436 (4 way)

Various positions available
5.0 mm pitch
Colour: Green
Screw connection
24-12 Wire Gauge Range

The Phoenix Contact's PCB connector has 2.5 mm² cross section and is black in colour. It has nominal current of 12 A and rated voltage (III/2) 320 V.

Connector system CLASSIC COMBICON
Type of contact Female connector
Pitch 5 mm
Number of positions 4
Drive form screw head Slotted (L)
Screw thread M3
Pin layout linear pinning
Locking no
Number of rows 1
Number of connections 4
Number of potentials 4

Phoenix Contact COMBICON 5.0mm Two Part Terminal Blocks

Datasheet - 1893313
