7TCA297020R0319 PSBF0530, Kopex Pliable Conduit, 25mm Nominal Diameter, Steel, Black, Кабелепровод

Kopex PVC Coated Steel Pliable Conduit, 30m Length, 27.3mm OD - PSBF Series - PSBF0530-RS

Protect wiring in challenging industrial environments with this conduit from Kopex. The galvanised steel construction means it's resistant to corrosion, crushing and impacts, while a PVC coating makes it flame-retardant and resistant to everything from acids and alkalis to salt water and UV rays. This means it's suitable for harsh indoor and outdoor conditions, including marine industry applications. As it's pliable, with a minimum bend radius of 45mm, it can be shaped by hand, making it easy to route around building infrastructures to speed up wiring installations.

Features & Benefits

• Wide operating temperature of -40°C to +105°C for use in demanding environments
• Length of 30m for use in large and complex installations
• Once C12 fittings are attached, it has an IP67 (ingress protection) rating, indicating it's dust-tight and waterproof

Applications

• Pump and fan connections
• Motor and starter circuits
• Electrical wiring

What's the diameter of this pliable conduit?

This conduit has an internal diameter of 20.4mm to accommodate one wide cable or multiple thin wires. It has an outer diameter of 27.3mm, making it easy to fit along narrow channels.

EMI Screened

In line with European Directives all equipment/installations should neither produce electromagnetic interference (EMI) or be affected by it. Cables in such cases should have an effective screen to protect against the effects of EMI. These conduits can contribute significantly to the EMI screen requirements of installations covered by the EMC Directive.

808751E Assembly Instructions

Datasheet
