RS SEB 6446 Ni / SW, Schutzinger Black Male Banana Socket, M4 Thread Termination, 32A, 1kV

The Schutzinger Safety threaded socket has 32 A rated current and 1000 V CAT III rated voltage, used for fixture in panels up to 6 mm thick also fixed by slotted nut M12 x 0.75
and spring washer using special tools MWZ 8 and MWZ 15 with black color.

Nickel-plated contact parts
Terminal M4
Maximum torque fastening nut 45 Ncm
Maximum torque nut M4 100 Ncm
Insulation PA 6.6 (Polyamide), UL94 - V2
Operating temperature from - 25 °C to + 80 °C

Datasheet - RS SEB 6446 Ni SW
