RS SEPB 6453 Ni / GNGE, Schutzinger Green, Yellow Male Banana Socket, Press-In Termination, 32A, 1kV, Nickel Plating

The Schutzinger Safety press-in socket has 32 A rated current and 1000 V CAT III rated voltage used for pressing into panels up to 6 mm thick fixed by using special tools MWZ 13 also, FR 6.3 mm x 0.8 mm terminal with green-yellow color.

Nickel-plated contact parts
Metal panels ≥ 1 mm
Plastic panels ≥ 2 mm
Insulation PA 6.6 (Polyamide), UL94 - V2
Operating temperature from - 25 °C to + 80 °C

Datasheet - RS SEPB 6453 Ni GNGE
