RS PRO Spring Plunger Microswitch, Screw Terminal, 15A @ 250V ac, SPDT, IP40

RS PRO 1NO/1NC Miniature Roller Plunger Micro Switch (15 A @ 125/250/440V)

The RS PRO miniature Micro Switch features a spring return plunger with a Nylon roller, Phenolic thermo-setting plastic case with a Beryllium Copper trident spring operating mechanism and a stepped base delivering a hard-wearing design that allows maximum creepage between terminals.
The RS PRO Micro Switch is designed with a snap action 1NO/NC contact arrangement with Nickel plated Brass screw terminals and a screwed plunger sleeve for single hole mounting.
The micro switch features Silver contacts avoiding the risk of contact oxidisation and maintaining secure and reliable conductivity throughout its mechanical life creating a hard wearing and consistent roller plunger switch ideal for a range of environments and applications.

Features and Benefits

• Roller Plunger actuator


• Contact Configuration SPDT


• Contact Arrangement 1NO/1NC


• Phenolic thermosetting plastic case


• Snap action


• Silver contacts


• Nickel plated M3.5 Brass screw terminals


• Single hole mounting


• Total weight of 82.6g

Approvals and Standards: CE, CSA, UKCA, IEC 1508-1
