651-105-04, Marl Red Panel Mount Indicator, 2V dc, 12.7mm Mounting Hole Size, Solder Tab Termination, Индикатор

LED Indicators 12.7mm Mount, 651 Series

10mm tinted diffused domed lens
Black anodised aluminium housing
IP67 rated
Fully internally potted
Shock and vibration resistant
Body designed to prevent rotation
0.11in. (2.8 x 0.5mm) terminals
6mm length solder terminal connection
Life Expectancy: 90000 Hours

Note

These LED indicators should not be operated without a suitable series resistor or other current-limiting device

Supplied with

sealing washer, fixing nut, lock washer.

10mm - 15.8mm Mounting

All products have a reverse voltage of 5V.
