BIP002E, BALLUFF Inductive Barrel-Style Proximity Sensor, M12 x 1, 17 mm Detection, PNP Output

The Baluff inductive positioning systems are up to the task even in tight installation conditions. et. A simple component of the machine, such as a rotary disk, can also function as a target. Measured values are relayed via IO-Link or as analog, depending upon the version. The primary field of application for the sensors is monitoring drive spindles and clamping devices. This positioning system can be used in mechanical engineering for many other applications with linear motion, such as determining punch depth, grip positions, roller placements, valve positions, etc. High reproducibility thus ensures optimum process quality.

Measuring range 0 to 17 mm
Interface IO-Link 1.1
Repeat accuracy per BWN±50.0 μm
Non-linearity maximum ±250 μm
Operating voltage Ub 18 to 30 VDC
Ambient temperature -25 to 70 °C
IP rating IP67

Datasheet - BIP002E
