RS PRO Straight Through Hole Pin Header, 6 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded

RS PRO, 6 Way, 2 Row, Straight Pin Header

Use this electrical connector from RS PRO to bridge printed circuit boards (PCBs) and transmit signals and current between them. For versatility, you can either use this connector to create board-to-wire setups with an electronic harness terminal or you can use it independently for board-to-board connections.


This connector can be through-hole mounted for a strong mechanical bond, so you can trust that it will stay in place for a long time. It's made from heat-resistant thermoplastic, so it won't be warped or damaged by reflow or soldering. The pin header has contacts made of highly conductive tin-plated brass for reliable electrical conductivity.


A PCB header like this one provides an efficient way to connect boards and wires. The contacts are also easy to remove from PCBs for use on prototypes that need revising.

Features and Benefits

• Straight body orientation


• Brass contact material


• Tin contact plating


• Current rating of 1 A


• Mating pin length of 7 mm


• Through-hole mounting type


• Six contacts


• Two rows


• Pitch of 2.54 mm


• Unshrouded


• Tail pin length of 3 mm


• Solder termination method


• Voltage rating of 650 V
