RS PRO Straight Through Hole Pin Header, 72 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded

RS PRO, 36-Way, 1 Row, 7 mm Length, Straight Pin Header

These size 5 straight pin headers feature a row of 36 male pins (or contacts) spaced 2.54 mm apart. The headers are unshrouded and come without a plastic guide box.

The connectors are crafted from glass-reinforced PBT (polybutylene terephthalate) – a robust and heat-resistant thermoplastic that operates at up to +200°C. They're tin-plated, giving them high electrical conductivity and protecting against oxidation. This plating also improves performance and durability. To achieve your desired length, simply snap the individual headers. They're through-hole mounted, which means that leads run through the circuit board. This lets the components withstand greater stress. Finally, solder termination provides a secure and permanent connection.

These types of pin headers can be used as a link between circuit boards. You can find them in everything from computers to cars.

Features and Benefits

• Unshrouded pin headers
• Size 5 – 7 mm (L) x 3 mm (W)
• 2.54 mm spacing between contacts
• 1 row of 36 contacts
• Mating pin length of 7.0 mm
• Straight body orientation
• Through-hole mounting
• Solder to terminate
• Brass contact material
• Tin contact plating
• Current rating of 4.0 A
• RoHS (Restriction of Hazardous Substances) compliant
• Conforms to ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 Electrostatic Control Standards
