VCCF1, Schneider Electric 3P Pole Panel Mount Isolator Switch - 32A Maximum Current, 11kW Power Rating, IP65

Schneider Electric Isolator Switch - VCCF1

Forming part of Schneider Electrics TeSys Vario Switch range is this isolator switch which is sometimes referred to as a switch disconnector. Comprised of a non-corrosive and resistant material that is suitable for harsh environments, this three-pole version is perfectly suited for manual motor control applications. Super easy to connect and wire as well as come undrilled which enables variable cable entry positions.

Features & Benefits

• Rotary type switch disconnector


• High-performance level


• The switch function of this device is an emergency stop


• 3 pole


• has an AC network type


• Extended rotary handle mounting style


• Aesthetically pleasing red handle and yellow front plate


• The rotary handle is padlockable up to 3 times


• Has a rated operational voltage of 690 V AC 50/60 Hz


• Mechanically durable up to 100000 cycles and has Electrical durability of 30000 cycles on DC-1...5, 100000 cycles on AC-21


• Supplied with handle assembly, shaft extension door interlock plate and terminal shroud


• Product standards - IEC 60947-3 and product certifications are CCC, CSA, GL and UL

How does an isolator switch work?

This type of isolator switch can sometimes be referred to as a switch disconnector, this is because it has been created and designed to safely isolate a circuit whilst it is being used or maintained. This isolator switch breaks or isolates a circuit through the rotation of the rotary handle and locking ring. This type of non-fused isolator switch will be found isolating circuit breakers, transmission lines, transformers and a multitude of other applications.

Schneider Electric Isolator Switch, 8kV Switch Rating, Screw Terminal Type - VARIO Series - VCCF1

Want to stay safe while you fix your kit? Choose this isolator switch from Schneider Electric. You can use it to disconnect the power to a particular circuit or machine when you need to carry out maintenance or repairs. The unit handles a maximum current of 32A and has a voltage rating of 690V AC, so it's suitable for demanding applications. As the assembly includes a red rotary handle, switch body and shaft extension, you've got everything you need for immediate installation.

Features & Benefits

• 3-pole configuration so it's suitable for motors, fans and other industrial machinery
• High switch rating of 8kV for safe operations at all times
• Wide operating temperature between -20°C and +50°C so it withstands tough environments
• Bright red handle and yellow front plate mean it's highly visible and can also serve as an E-stop
• Shock resistance of 30gn means you can use it in heavy industrial applications

Applications

• Automotive manufacturing
• Textile production
• Paper mills

Can I secure this isolator switch?

The unit has space for up to three padlocks to prevent accidental or unauthorised use.

How long will this switch last?

It has a mechanical durability up to 100,000 cycles, so it's highly reliable over long periods.
