Weller Xcelite T0051502599N, 160 x 235mm PCB Holder

Xcelite by Weller T0051502599N PCB Holder-(ESF 120)

Introducing a superb PCB holder from Weller. This handy workmate delivers in every department, it’s easy to assemble, offers multi-position settings and sits securely on any workbench or work station. The Ideal workmate for engineers or DIY enthusiasts.

Why would you buy this circuit board holder?

During soldering applications it can be tricky to hold and solder components and typically this leaves you at risk from burns, the Weller T0051502599N PCB holder overcomes all these issues leaving you hands-free to manoeuvre circuit boards and work in comfort with more control.

How does the PCB holder work?

Weller T0051502599N PCB Holder has dual rod bars with adjustable triangulated support arms that slide to the required position then locked into place by tightening the locking wheels. A PCB is supported by spring adjustable jaws that can be rotated in either direction via a turn handle. There's also a lever that holds components in place on PCB so you can solder from the reverse side without them falling out.

Features and Benefits

• Maximum clamping area 160 x 235 mm


• Parts positioned to allow rotation through 360°, can be snapped into place 15° intervals


• Circuit board support by spring force


• Side parts infinitely adjustable, clamping with hex socket head screws


• Anti-slip thanks to integrated rubber feet


• Good stability thanks to the low centre of gravity


• Movable arm with cushion clamps for securing components


• High-quality, technical plastic & metal parts in the corrosion-resistant design


• Offset by 90° to clamping profile, various options for clamping to a wide range of accessories, geometries, e.g. round parts, diode connectors or similar, square parts, soldering strips


• Weight: 460 g

Typical Applications

• Electronic Servicing


• Soldering


• PCB Handling


• DIY Applications


• Universal Applications

FAQ's

PCB's prone to slipping out?

The jaws that hold the printed circuit board have grooves that allow for superior support and eliminates slippage.
