X-NUCLEO-OUT09A1, STMicroelectronics Expansion Board Power Management for IPS8160HQ for Programmable Logic Controllers

The X-NUCLEO-OUT09A1 industrial digital output expansion board for STM32Nucleo provides a powerful and flexible environment for the evaluation of the driving and diagnostic capabilities of the IPS8160HQ octal high-side smart power solid state relay, in a digital output module connected to 0.7 A industrial loads.

The X-NUCLEO-OUT09A1 interfaces with the microcontroller on the STM32 Nucleo via 5 kV optocouplers driven by GPIO pins and Arduino R3 connectors.

The expansion board can be connected to either a NUCLEO-F401RE or a NUCLEO-G431RB development board.

It is also possible to evaluate a system composed of a X-NUCLEO-OUT09A1 stacked on other expansion boards.

• Based on the IPS8160HQ octal high-side switch, which features:Operating range 10.5 to 36 VLow power dissipation (RFast decay for inductive loadsUnder-voltage lock-outOverload and over-temperature protectionsLoss of ground protectionQFN48L 8x6 mm package


• Application board voltage operating range: 15 to 33 V


• Extended voltage operating range (J9 open) up to 36 V


• Operating current: up to 0.7 A per channel


• Green LEDs for outputs on/off status (J12 and J13 close 1-2, 3-4, 5-6, 7-8)


• Red LED for common overheating diagnostic (SW2 close 2-3)


• 5 kV galvanic isolation


• Supply rail reverse polarity protection


• Compatible with STM32 Nucleo development boards


• Equipped with Arduino UNO R3 connectors


• RoHS and China RoHS compliant

Datasheet - X-NUCLEO-OUT09A1
