XCSA502, Telemecanique Sensors XCSA Safety Interlock Switch, 2NO/1NC, Keyed, Zinc Alloy, Выключатель

XCSA Safety Interlock Switch

3 positive opening contacts as standard (on guard opening)
A key operated lock enables positive locking of the guard
Optional version with orange LED to indicate guard open/closed
Heavy duty metal DIN style
Turret heads can be rotated through 360° in 90 steps
8 actuator entries and 1 tapped entry
20N minimum operating force for positive opening
IP67 rating
Productivity is increased due to the third contact dedicated to diagnostics
Preventa XCS Safety Switches

Note

Actuators must be purchased separately, see accessories table

Standards

Conforms to EN1088, EN60204

Telemecanique Sensors Rotating Hinge Switch

The Telemecanique sensors XCSA series interlock switch has 1NC/2NO switch configuration. It has a maximum voltage of 240VAC/250VDC and a maximum current of 6A. The housing material is zamak and it is available in a screw connection type.

Features and Benefits

• 3 positive opening contacts as standard (on guard opening)
• Key operated lock enables positive locking of the guard
• Optional version with orange LED to indicate guard open/closed
• Heavy duty metal DIN style
• Turret heads can be rotated through 360° in 90 steps
• 8 actuator entries and 1 tapped entry
• 20N minimum operating force for positive opening
• Productivity is increased due to the third contact dedicated to diagnostics
• Operating temperature ranges between -25°C and 70°C

Certifications

• IP67 rated
• EN1088
• EN60204
• EN/IEC 60947-5-1
• CSA C22.2 No 14
• EN/ISO 12100
• EN/IEC 60204-1
• EN 1088/ISO 14119
• UL 508

Standards

Conforms to EN1088, EN60204.
