Microchip PIC16F1778-E/MX 8 bit MCU Microcontroller MCU, PIC16, 25-Pin MX

The Microchip PIC16F177X microcontrollers feature a high level of integration of Intelligent Analog and digital peripherals for a wide range of applications, such as lighting, power supplies, battery charging, motor control and other general purpose applications. These devices deliver multiple Op Amps, 5 to 10 bit DACs, High Speed Comparators, 10-bit ADC, 10 to 16 bit PWMs, Programmable Ramp Generator and other peripherals that can be connected internally to create closed loop systems without using pins or PCB area. The 10 and 16-bit PWMs, the Digital Signal Modulator and tristate output Op Amp can be used together to create a LED dimming engine. The Peripheral Pin Select functionality provides flexibility, eases PCB layout and peripheral utilization by allowing digital peripheral pin mapping to any I/O.

Enhanced Mid range Core with 49 Instruction 16 Stack Levels
Flash Program Memory with self read and write capability
128 Bytes of Non Volatile Data Storage High-Endurance Flash
Internal clock speeds from 32MHz to 31kHz
3times Op Amps
3times 10-bit DACs
3times 5 bit DACs
6times High Speed Comparators
10 bit ADC with 17 channels
Zero Cross Detect
3times Programmable Ramp Generator
3times 10 bit PWMs
3times 16 bit PWMs
2times 100mA I/Os
3times Capture, Compare, PWM
3times Complementary Output Generator
4times Configurable Logic Controller

Datasheet - PIC16F1778-E/MX
