RS PRO DIN Rail Mounted Current Transformer, 60 → 200A Input, 330 mV

RS PRO Three Phase 160 A, 330mV Output Plug and Play, Current Transformer, RJ45 Easywire Connection

From RS PRO this is the three phase 160 A Plug and Play current transformer part of the easywire family of current transformers and energy meters all designed for quick and easy connection saving you up to 90% installation time compared to standard current transformer and meter installations. The RS PRO three phase current transformer will monitor the current in industrial and commercial equipment applications plus the built-in limiting circuitry of the current transformer’s secondary is always under load clamped to a safe level meaning the output connection can be disconnected safely while under load. The design of the current transformer is complete with Snap-on DIN rail fixing, captive busbar location screw fixings, insulated busbar location feet, sealable (anti-tamper) RJ45 horizontal connection sockets plus the current transformer has moulded loaded direction indication arrows on the transformer shoulders.

Features & Benefits

• 3-Phase, 160 A


• Accuracy Class 1 to IEC/EN60044-8, IEC/EN61869-2


• IP40 Housing, IP20 Terminals


• Sealable RJ45 Easywire connection 330mV


• Passing cable primary winding


• Rj45 connection secondary winding


• Fits standard moulded circuit breaker frame sizes


• 35 mm Bar centres


• 105 mm width


• 25 mm x 21 mm Apertures


• Weight 550 g


• Part of the easywire RS PRO range of current transformers


• Built-in limiting circuitry


• 47 to 63 Hz frequency


• 100% Rated current


• Dry transformer, air insulation Class B


• Made from Self-extinguishing polycarbonate


• Foot, Busbar or Snap-on 35 mm DIN rail mounting


• Easy operation and install, saves 90% installation time

Applications

• Monitoring current within industrial and commercial applications

What does the Easywire design provide?

• Allows for plug-in connectors to be used in current transformers and energy meters


• RJ45 leads connect between 3-Phase meters and current transformers


• Excellent labour savings


• Eliminates wiring errors


• Increased safety


• No need for shorting
terminals

• Easy, quick, simple plug-in connection for current and voltage inputs/outputs


• Reduced testing time


• EMC Tested and CE Certified

Why RS PRO?

RS PRO is the own brand of RS. The RS PRO Seal of Approval is your assurance of professional quality, a guarantee that every part is rigorously tested, inspected, and audited against demanding standards. Making RS PRO the Smart Choice for our customers.
