RS PRO 3-Phase Backlit Multi-Function Power Energy Meter, Pulse Output and Modus, MID Certified DIN96 Panel Mounted
From RS PRO this is the MID approved panel mounted multi-function power / energy meter providing you with a wealth of benefits to accurately measure and monitor energy usage. With a white backlit LDC digital display complete with an 8-digit resolution providing clear readings in all light conditions plus quick select push buttons on the front of the energy meter fast access to a display page. The RS Pro digital multi-function energy meter is not only suitable for monitoring precise energy consumption but also for various other electrical readings plus is complete with true RMS measurement, pulse output, RS485 Modbus communication all housed within a compact DIN 96 casing.
Features & Benefits
- 3-Phase, 4-wire connection
- MID Certified for 3 x 230 V / 400 V ±10%
- 6 A, 1.2 Nominal maximum current
- RS485 communication
- Modbus RTU Protocol
- Pulse output
- True RMS measurement
- High definition white backlit LCD display
- Manual or auto scroll screen modes
- Panel mounting with maximum 6 mm panel thickness
- Polycarbonate UL94 V-0 housing, weighs 320 g
- Compact size, 50 mm panel depth
- Screw clamp current input, voltage input, communication terminals
- Easy operation and programming
Display Parameters
- Voltage 0.5% of full scale
- Current 0.5 % of full scale
- Power factor 1%b of unity
- Current and voltage total harmonic distortion
- Neutral current, calculated
- Frequency 0.1% of full scale
- Hours run, hours and minutes
- Power, active, reactive, and apparent
- Energy Active Class 1, Class B (IEC/EN62053-21, IEC/EN50470-3)
- Reactive Energy Class 2 (IEC/EN62053-23)
- Total harmonic distortion up to 31st, 3%
Applications
- Monitoring energy consumption
- Residential
- Solar PV
- Industrial and commercial utility applications
Why RS PRO?
RS PRO is the own brand of RS. The RS PRO Seal of Approval is your assurance of professional quality, a guarantee that every part is rigorously tested, inspected, and audited against demanding standards. Making RS PRO the Smart Choice for our customers.
Техническая спецификацияRS PRO Datasheet
