RS PRO 1, 3 Phase LCD Energy Meter, Type Energy Meter

RS PRO 4-Module Backlit Multi-Function Power Energy Meter, Pulse Output and Modus, MID B + D Certified DIN96 DIN Rail Mounted

From RS PRO this is the MID approved DIN Rail mounted multi-function power / energy meter providing you with a wealth of benefits to accurately measure and monitor energy usage. With a white backlit LDC digital display complete with clear readings in all light conditions plus quick select push buttons on the front of the energy meter fast access to a display page. The RS Pro digital multi-function energy meter is not only suitable for monitoring precise energy consumption but also for various other electrical readings plus is complete with pulse output, RS485 Modbus communication all housed within 4-module DIN 43880 polycarbonate casing.

Features & Benefits

• 3-Phase, 4-wire connection


• MID B + D Certified


• 6 A, 1.2 Nominal maximum current


• RS485 communication


• Modbus RTU Protocol


• Pulse output


• High definition white backlit LCD display


• Manual or auto scroll screen modes


• DIN Rail mounting with Snap-on 35 mm rail


• Polycarbonate UL94 V-0 housing, weighs 215 g


• Screw clamp / rising clamp current input, voltage input, communication terminals


• Easy operation and certified for billing purposes

Display Parameters

• Voltage 0.5% of full scale


• Current 0.5 % of full scale


• Power factor 1%b of unity


• Frequency 0.1% of full scale


• Power, active, reactive, and apparent


• Energy Active Class 1, Class B (IEC/EN62053-21, IEC/EN50470-3)


• Reactive Energy Class 2 (IEC/EN62053-23)


• Energy maximum display 9999999

Applications

• Monitoring energy consumption


• Residential


• Industrial and commercial utility applications
