RS PRO 1, 3 Phase LCD Energy Meter, Type Energy Meter

RS PRO Single or 3-Phase Backlit Multi-Function Power Energy Meter, Pulse Output and Modus, DIN72 Panel Mounted

From RS PRO this is the panel mounted multi-function power / energy meter providing you with a wealth of benefits to accurately measure and monitor energy usage. With a white backlit LDC digital display complete with an 8-digit resolution providing clear readings in all light conditions plus quick select push buttons on the front of the energy meter fast access to a display page. The RS Pro digital multi-function energy meter is not only suitable for monitoring precise energy consumption but also for various other electrical readings plus is complete with true RMS measurement, pulse output, RS485 Modbus communication all housed within a compact DIN 72 casing.

Features & Benefits

• Single phase L1, L2, L3 CT, 3-Phase 3 Wire, 3-Phase 4-wire connection


• 11 to 300 V Input voltage range


• 1.2 A, 6 A (Nominal 1.2) maximum current


• RS485 communication


• Modbus Protocol


• 1 x Pulse output


• True RMS measurement


• Multiple meter connection with BUS 32 (up to 255 with RS485 repeater)


• High definition white backlit LCD display


• Manual or auto scroll screen modes


• Panel mounting with maximum 6 mm panel thickness


• Polycarbonate UL94 V-0 housing, weighs 320 g


• Screw clamp current input, voltage input, communication terminals


• Easy operation and programming

Display Parameters

• Voltage, L-L, L-N and average


• Current – Phase, total and maximum demand


• Power factor per phase and average


• Current and voltage total harmonic distortion


• Neutral current, calculated


• Frequency


• Hours run, hours and minutes


• Power, active, reactive, and apparent


• Power minimum/maximum demand – active, reactive, and apparent


• Energy Active – active, reactive, and apparent


• Import and export energy -active, reactive, and apparent

Applications

• Monitoring energy consumption


• Residential


• Industrial and commercial utility applications
