RS PRO 1, 3 Phase LCD Energy Meter, Type Energy Meter

RS PRO Single or 3-Phase Backlit Easywire Multi-Function Power Energy Meter, Pulse Output and Modus, MID B + D Certified DIN 96 Panel Mounted

From RS PRO this is the MID approved panel mounted easywire multi-function power / energy meter providing you with a wealth of benefits to accurately measure and monitor energy usage. With a white backlit LDC digital display complete with an 8-digit resolution providing clear readings in all light conditions plus quick select push buttons on the front of the energy meter fast access to a display page. The RS Pro digital multi-function energy meter is not only suitable for monitoring precise energy consumption but also for various other electrical readings plus is complete with true RMS measurement, pulse output, RTU Modbus communication all housed within a compact DIN 96 casing. The easywire system is specially designed saving you up to 90% installation time compared to standard meters and current transformers

Features & Benefits

• Single please (CT on L1 only), 3-Phase 4-wire connection


• MID Certified for 100 to 240 V


• Easywire 1.2 A (1.2 A Nominal) maximum current


• Easywire quick connection system


• RS485 communication


• Modbus RTU Protocol


• 1 x Pulse output


• True RMS measurement


• High definition white backlit LCD display


• Manual or auto scroll screen modes


• Panel mounting with maximum 6 mm panel thickness


• Polycarbonate UL94 V-0 housing, weighs 240 g


• Current input Rj45 – easywire input terminal


• Rising clamp pluggable terminal block voltage input, communication terminals


• Easy operation and programming

Display Parameters

• Voltage 0.5% of full scale


• Current 0.5 % of full scale


• Power factor 1% of unity


• Current and voltage total harmonic distortion


• Neutral current, calculated


• Frequency 0.1% of full scale


• Hours run, hours and minutes


• Power, active, reactive, and apparent


• Energy Active Class 1, Class B (IEC/EN62053-21, IEC/EN50470-3)


• Reactive Energy Class 2 (IEC/EN62053-23)


• Total harmonic distortion up to 31st, 3%

Applications

• Monitoring energy consumption


• Residential


• Industrial and commercial utility applications
