RS PRO 3 Phase LCD Energy Meter, Type Energy Meter

RS PRO 4-Module, Plug and Play, Backlit, Easywire Multi-Function Power Energy Meter, Pulse Output and Modus, MID B + D Certified, DIN 43880 DIN Rail Mounted

From RS PRO this is the MID approved DIN Rail mounted easywire multi-function power / energy meter providing you with a wealth of benefits to accurately measure and monitor energy usage. With a white backlit LDC digital display providing clear readings in all light conditions plus quick select push buttons on the front of the energy meter fast access to a display page. The RS Pro digital multi-function energy meter is not only suitable for monitoring precise energy consumption but also for various other electrical readings plus is complete with pulse output, true RMS, Modbus communication all housed within a compact DIN 43880 4-module casing. The easywire system is specially designed saving you up to 90% installation time compared to standard meters and current transformers plus the energy meter has 3-phase metering circuits in one case and accepts inputs from two separate easywire 3-phase current transformers utilizing the same voltage.

Features & Benefits

• 3-Phase 4-wire connection


• MID B + D Certified


• Easywire 1.2 A maximum current


• 2 x easywire 1 A nominal current input


• Easywire quick connection system


• RS485 communication


• Modbus Protocol


• 2 x Pulse output


• True RMS measurement


• High definition white backlit LCD display


• Manual by key or auto scroll screen modes


• Snap on 35 mm DIN Rail Mounting


• Polycarbonate UL94 V-0 housing


• Current input 1.2 A maximum – easywire


• 2 x easywire 1 A Nominal current input


• 2 x Rj45 input terminal type


• Pluggable terminal block screw clamp voltage input / output, communication terminals


• Easy operation and programming

Display Parameters

• Voltage 0.5% of full scale


• Current 0.5 % of full scale


• Power factor 1% of unity


• Frequency 0.1% of full scale


• Power, active, reactive, and apparent


• Energy Active Class 1, Class B (IEC/EN62053-21, IEC/EN50470-3)


• Reactive Energy Class 2 (IEC/EN62053-23)

Applications

• Monitoring energy consumption


• Residential


• Split-load lighting


• Power boards


• 3-Phase applications


• Certified for billing purposes


• Industrial and commercial utility applications
