RS PRO, Accessory Type Ethernet Communication Module

RS PRO Modbus Ethernet Power Quality Input Module

When you need an Input Module to add-in to the RS PRO digital DIN 96 power quality analyser multi-function meter, this Modbus ethernet power quality input module, when connected, automatically recognises the RI-F550 RS PRO multi-function meter (stock number 2641020). This input module is one of up to four input modules that can be added into the multi-function meter allowing the analyser to increase the functions for inputs and outputs providing a full system integration with Smart electricity distribution components including energy management systems.

Features & Benefits

• Modbus Ethernet Power quality input module


• 1 x 10M RJ45 network interface


• Supports 802.3 standard Ethernet framework


• Working mode TCP Server


• DHCP Support for automatic IP acquisition


• Pre-programmed globally unique Node MAC address


• Supports standard Modbus TCP protocol


• Reliable TCP connection


• Dimensions 59.5 mm x 41 mm x 20 mm


• Extends the functionality of RS PRO Multi-function meter analyser

Input and Output Features

All the below functions can be expanded on a multi-function meter analyser by using plug-in modules

• RS485 Modbus


• Energy pulse output


• 2 x AC Digital inputs


• 1 x Relay outputs


• Neutral current transformer input

Applications

• Expanding functions for a meter analyser in electrical parameter measurement and power quality analysis

Why RS PRO?

RS PRO is the own brand of RS. The RS PRO Seal of Approval is your assurance of professional quality, a guarantee that every part is rigorously tested, inspected, and audited against demanding standards. Making RS PRO the Smart Choice for our customers.

Modules available for increased Functionality

• Stock number 2641021 Dual Pt100 Input module for Power Quality Analyser


• Stock number 2641022 Modbus Ethernet module for Power Quality Analyser


• Stock number 2641023 Mbus module for Power Quality Analyser


• Stock number 2641024 BacNet TCP/IP module for Power Quality Analyser


• Stock number 2641025 BacNet RS485 module for Power Quality Analyser
