RS PRO 1 Phase LCD Energy Meter, Type Energy Meter

RS PRO Single Module, Single Phase, Direct Connect 45 A, Backlit, Power Energy Meter, Pulse Outputs, MID Certified, DIN Rail Mounted

From RS PRO this is the MID approved DIN Rail mounted power / energy meter providing you with a wealth of benefits to accurately measure energy usage. With a white high definition backlit LDC digital display providing clear readings in all light conditions. The RS PRO digital energy meter is not only suitable for monitoring precise energy consumption but versatile and suitable for different applications plus does not require additional current transformers. As the energy meter has MOD certification it assures accuracy, build quality plus certified for billing purposes.

Features & Benefits

• Single phase connection


• MID Certified


• 45 A maximum current


• 230 V ac input voltage


• Pulse output


• High-definition white backlit LCD display


• Auto scroll screen modes


• DIN Rail Mounting


• Polycarbonate UL94 V-0 housing


• IP20 Terminals, IP51 housing front


• Screw type, rising clamp input and output terminals


• Easy operation

Display Parameters

• Active energy Class 1, Class B (IEC/EN62053-21, IEC/EN50470)


• Voltage, Current – 0.5% of full scale


• Active power 1%


• Power factor 1% of unity


• Frequency 0.1% of full scale

Applications

• Monitoring energy consumption


• Residential


• Solar PV


• Certified for billing purposes


• Industrial and commercial utility applications

Why RS PRO?

RS PRO is the own brand of RS. The RS PRO Seal of Approval is your assurance of professional quality, a guarantee that every part is rigorously tested, inspected, and audited against demanding standards. Making RS PRO the Smart Choice for our customers.

RS PRO Datasheet
