RS PRO MCB, 2P, 10A Curve C, 240V AC, 240V DC, 6 kA Breaking Capacity

RS PRO 240 V DIN Rail Mounted DHMZ Series of MCB’s (miniature circuit breakers) Type B (curve), Type C (curve)

For reliability, efficiency and up to date technology the RS PRO range of MCB’s (miniature circuit breakers) offer you a selection of MCBs designed to protect your electrical circuits from both overloads and short-circuits, meeting the needs of residential, commercial, and industrial applications.

With breaking capacities of up to 10 KA all in accordance with IS/IEC 60898-1 and IS/IEC60947-2 RS PRO MCB’s include many features including inspection windows, safety terminals, large cable terminals, Bi stable clip, positive contact indication, auxiliary contacts, and air circulation. All offered with IP20 protection within a thermoplastic flame-retardant moulded casing for clip on DIN rail mounting. With a choice of 1 to 4 Poles, rated currents of 0.5 to 63 A, independent thermal magnetic tripping system, type B and Type C MCB’s provide the short circuit electrical protection necessary for many applications.

Miniature Circuit Breakers, MCB, is the standard recognized term for MCB but also recognized as Circuit Breakers, Mini Circuit Breakers, Trip Switches, Circuit Protectors and Breakers.

Features & Benefits

• 240 V MCB


• Type B and Type C (curve)


• Inscription window for circuit identification


• Safety terminals, guide a cable to the cage terminal


• Up to 35 mm² large cable terminals


• Dual position DIN Rail clamp with Bi stable clip


• Red-ON, Green-OFF positive contact indication


• Air circulation around individual poles


• Fitted auxiliary contacts


• Thermoplastic high strength housing, flame retardant


• IP20 Protection


• Standards IS/IEC 60898-1 and IS/IEC60947-2


• Quick and easy to use

Applications Type B MCB

• For Domestic residential protection applications with Resistive loads


• Lighting, lamps, LED, heating, small appliances, power outlets, general lighting

Applications Type C MCB

• Used for commercial and industrial applications with Inductive loads


• IT Servers, motors, transformers, larger lighting circuits and many more

A Miniature circuit breaker is simply an electrical switch designed to protect your electrical circuits and any connected equipment from an overload and short circuit. Essential for use within domestic residential, commercial, and industrial distribution preventing danger and damage from electrical fires. MCB’s are designed with various current ratings to suit different circuits and loads. Always ensure you size and install according to manufacturer instructions to protect you, and your electrical system safely.

Why RS PRO?

RS PRO is the own brand of RS. The RS PRO Seal of Approval is your assurance of professional quality, a guarantee that every part is rigorously tested, inspected, and audited against demanding standards. Making RS PRO the Smart Choice for our customers.
