MY2-GS-R DC100/110, Omron Plug In Power Relay, 100 → 110V ac Coil, 10A Switching Current, DPDT

OMRON Power Relay, 20ms Maximum Operation Time, 100mΩ Contact Resistance - MY Series - MY2-GS-R DC100/110

Need a space-efficient switching solution for your electrical appliances? Go for this power relay from OMRON. With compact dimensions of 28 (L) x 21.5 (W) x 36mm (H), it fits right into setups with limited space. When paired with a plug-in socket, it reduces your wiring by 60% and makes installation speedy. The device generates a magnetic field that closes its contacts when energised, letting you smoothly control the power supply to your equipment with reliable repeatability. It tips the scales at just 75g, so it's easy to handle during assembly.

Features & Benefits

• 2kV AC dielectric strength shows that it handles high voltages without losing form
• Safe to use in challenging settings, thanks to an operating temperature range between -55°C and +70°C
• Mechanical and LED indicators make it easy to monitor and diagnose faults
• Release time of 20ms for speedy resets in fast-paced applications

Applications

• Automotive industry
• HVAC systems
• Process and packaging industry

Why do I need a power relay?

A power relay has the advantage over a mechanical switch of being able to control high-power loads without suffering burnout.

Datasheet - MY2-GS-R DC100/110

Brochure - Industrial Relays
