MY4-GS-R AC24, Omron Plug In Power Relay, 24V ac Coil, 6A Switching Current, 4PDT

OMRON Power Relay, 20ms Response Time, +70°C Maximum Operating Temperature - MY Series - MY4-GS-R AC24

Control the flow of electrical current in your industrial applications with this power relay from OMRON. It's an electromagnetic switch that uses a low input to trigger a high-energy circuit, telling it to turn on and off. The device has silver alloy contacts that hold their ground against wear and impact to perform over long periods. As it weighs in at just 35g, it puts minimal strain on your mounting surface. With dimensions of 28 (L) x 21.5 (W) x 36mm (D), this compact option fits easily into applications where space is tight.

Features & Benefits

• Wide operating temperature range between -55°C and +70°C means it performs in tough conditions
• Plug-in termination makes installation easy without the need for special tools
• Mechanical endurance of up to 50 million cycles for long-lasting service
• Dielectric strength of 2kV AC prevents arcing between internal components for electrical safety

Applications

• Measurement and instrumentation devices
• Renewable energy systems
• Telecommunications industry

What's the response time of this device?

This power relay has a fast response time of 20ms, so it's suitable for applications where rapid reactions are crucial.

Datasheet - MY4-GS-R AC24

Brochure - Industrial Relays
