LA1KN31, Schneider Electric Auxiliary Contact, 4 Contact, 1NC + 3NO, Front Mount, TeSys K

Schneider Electric Auxiliary Contact, Instantaneous Operation, -25°C to +50°C Operating Temperature - LA1K Series - LA1KN31

Need to expand the switching function of a contactor in your machinery? Turn to this auxiliary contact from Schneider Electric. When the contact position of the main contactor changes, this unit sends a signal to the controller to indicate the operating status of the connected equipment. To help you put together a complete assembly, it's designed for use with LC1K, CA2K and CA3K contactors from the TeSys K range. Thanks to its instantaneous contact operation, you can rely on this device for rapid signal transmissions.

Features & Benefits

• Ambient operating temperature range of -25°C to +50°C for safe use in challenging environments
• IP20 rating indicates it's protected against objects over 12mm in size
• Contact current rating of 10A for use in low-power devices
• Light weight of 45g for minimal strain on main contactor

Applications

• Automated industrial systems
• Control cabinets
• HVAC equipment

How do I mount this auxiliary contact?

Thanks to the screw terminals, it's simple to mount this auxiliarycontact by securely attaching it to the front of your contactor. This creates a mechanical link to ensure it precisely monitors the operation of the main contacts.

K Mini Control Relays References

Datasheet

Line Drawing - LA1KN31

Catalogue - Motor Starters

2796337_Line Drawing.pd

Product Environmental Profile
