RS PRO PIR Sensor

RS PRO Wall PIR Switch Detector, PIR, Wall Mount, 220 to 240 V ac

The RS PRO wall switch detector uses a passive infrared sensor to work out whether someone is in the room and can also detect when it's getting dark. It's suitable for both residential and commercial settings, such as offices, retail units and warehouses.

This device is capable of switching on up to 10 A of electricity output for traditional incandescent light bulbs or 6 A with fluorescent lighting. The sensor uses body heat to detect occupancy at distances of up to seven metres. It also offers an adjustable time period of up to 30 minutes, so appliances won't switch off while an area is still occupied.

For easy assembly, it can be installed flush or mounted onto the surface of any standard British back box with a depth greater than 25 mm. This detector is available for use with both standard lighting and electrical appliance applications.

Features and Benefits

• Detector
• Wall mounting
• Passive infrared (PIR) sensor
• Height of 19 mm
• Length of 86 mm
• Width of 86 mm
• Voltage rating of 220 to 240 V AC
• Range of 7 m
• Time delay of 10 sec to 60 mins
• Suitable for switching up to 16 A with resistive loads or 6 A with fluorescent lighting
• Override switch allows lights to be switched off permanently
• EMC-2004/108/EC and LVD-2006/95/EC compliant for safety

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
