D2475, Sensata / Crydom SERIES 1 Series Solid State Relay, 75 A rms Load, Surface Mount, 280 V rms Load, 32 V Control, Реле

Sensata | Crydom Solid-State Relay, Zero-Cross Switching Type, SCR Output - Series 1 Series - D2475

For fault-free switching in your equipment, fit this solid-state relay from Sensata | Crydom. As it uses electrical switching, there are no moving parts, giving you a speedy switching device that won't wear out. Its zero-cross switching function keeps electrical noise low and prevents inrush currents from causing problems. An SCR output and a current rating of 75A enable it to handle high-power circuits and heavy industrial loads. Use this relay in applications such as machine automation, motor control devices and HVAC appliances.

Features & Benefits

• Direct-bond copper substrate efficiently transfers heat for cool operation
• Flame-retardant housing for safety in the event of a fire
• Pre-drilled holes for simple surface mounting
• Anti-rotation barriers prevent twisting for secure installation
• Operating voltage range of 24 to 280V AC for use in low-voltage systems

What type of electrical terminals does this SSR have?

This SSR uses screw terminals to clamp your wires securely in place. All you need is a simple screwdriver, making it a breeze to connect your wires.

Approvals

UL; CSA; VDE

Crydom Solid State Relay and Accessories

CSA 0816890000

UL E116950

UL REC FOR CANADA E116950

VDE 10143

Series1 240VAC Datasheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)

Line Drawing - D2475
