8LS1-4C, Honeywell LS Series Plunger Limit Switch, NO/NC, IP67, SPDT, Die Cast Zinc Housing, 480V ac Max, 10A Max

Honeywell Snap-Action Plunger Limit Switch, 550V DC, 480V AC - LS Series - 8LS1-4C

Use this plunger-style limit switch from Honeywell to control your machinery or limit the movement of your mechanical equipment. As it has snap-action contacts, it ensures a fast switching action for rapid response times. Its rugged die-cast zinc exterior makes it resistant to impact and corrosion for use in harsh industrial environments. The switch also has an IP67 (ingress protection) rating, meaning it's completely dust-tight and can withstand submersion in up to 1m of water for up to 30 minutes. The stranded steel cable is resistant to impact and abrasion for enhanced durability.

Features & Benefits

• Wide operating temperature range of -29°C to +71°C for use in hot and cold environments
• Non-marking actuator won't damage objects it touches

Applications

• Machine tool equipment
• Material handling
• Valve actuation
• Food and beverage industry

Does this plunger limit switch run on AC or DC power?

This plunger limit switch is compatible with AC and DC circuits, making it a versatile choice. It supports a maximum voltage of 480V AC or 550V DC for use in high-power applications.

Approvals

UL; CSA

MICRO SWITCH™ Datasheet

Product Range Guide - Limit Switches & Machine Safety
