RS PRO 9 Way Right Angle Through Hole D-sub Connector Socket, 2.54mm Pitch, Разъем

RS PRO 9 Way Right Angle Through Hole D-Sub Connector Socket, 2.54mm Pitch

This RS PRO 9-way D-Sub connector is specially designed to mount onto a printed circuit board (PCB). Thanks to its narrow profile and built-in solder points, it's an easy-to-use option.

The right-angle microminiature connector is light, as it’s housing is made from aluminium with yellow chromate over cadmium plating. It has gold-plated copper-alloy contacts and these are made from a precision miniature spring cable with a welded tip. Secure mating takes place through two jackposts. Set in cavities, the pin contacts are protected from moisture. A silicone elastomer interfacial seal keeps the pins isolated from each other and from the metal shell. Insulation comes courtesy of UL94V-0 glass-filled polyester.

Due to its short signal paths, this 2.54 mm connector is often found in military environments. It’s used for miniaturised airborne electronics as well as data-processing equipment.

Features and Benefits

• Right angle orientation
• 9 gold-plated copper-alloy contacts to conduct your signal
• Housed in aluminium alloy
• 2.54 mm pitch
• 3.0 A current rating
• Measures 19.94 mm x 15.5 mm
• Minimum operating temperature of -55°C
• Maximum operating temperature of +135°C
• Meets MIL-C-83513 standards for its polarised shell with soldered micro-miniature connectors

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

Standards

MIL-C-83513

RS PRO Datasheet
