840.400.00, Werma 840 Series Clear Steady Effect Beacon Unit, 12 → 230 V ac/dc, AC, DC, IP54

Stacking Signal Tower - KombiSIGN 70, 70mm, IP54

The WERMA KombiSIGN 70 modular stacking signal tower is an ideal solution to the increasing requirement for safety, machine productivity and reduced downtime. The modular design of these stacking towers enables quick and easy installation. Each KombiSIGN module is equipped with a bayonet fixing with integral contact system. Simply align the corresponding white marks and gently twist to lock them in place.

Features and Benefits

• Suitable for machine and manual Andon indication
• Modular system allows a completely free combination of optical and audible signal elements
• Mechanical and electrical connection of the elements in the space of seconds using a bayonet connection system
• Completely safe element changes (contact-voltage proof) without the need for tools
• Protection rating IP54 for use in normal conditions
• Up to 5 elements can be mounted on a terminal base
• Flexible combination of optical and audible elements
• Optical isolation due to O-ring seal stopping illumination of adjacent element
• Operating voltage for the continuous incandescent element is dependant on bulb fitted
• LED EVS elements have an extremely bright, random sequence of light to immediately grab attention
• Ultra-bright elements are up to 20 times brighter than conventional LED beacons. Intelligent electronics ensure operation at maximum brightness
• Vocal element plays customer specific audio files in mp3 format (sounds, alarms, music or spoken word)
• Operating temperature range is -20 to +50 °C
• Polyamide body with polycarbonate lenses, 70 mm diameter

Permanent Multi-colour LED Light Element

• Seven colours in one beacon
• Different colours can be triggered via the pins in the terminal element
• Positive and negative control logic
• The three basic colours (red/yellow/green) can be triggered using only two PLC outputs
• High light intensity

Note

Lamps are not supplied and must be purchased separately. Not compatible with KombiSIGN 71.

Approvals

UL listed, CSA, VDE

WERMA Beacon Unit, Bayonet Connection, 65g Weight - KombiSIGN 70 Series - 840.400.00

Shine a light on critical equipment conditions with this beacon unit from WERMA. It delivers a steady white beam when actuated, which is commonly used to indicate a machine is running. The unit's durable PC housing withstands wear and impact, so you can rest assured of long-lasting service in tough environments. Thanks to its modular design, you can mount it alongside other beacons to create a complete signal tower.

Features & Benefits

• IP54 rating tells you it's protected against limited amounts of dust and water sprays in all directions
• Light weight of 65g makes it easy to handle during installation
• Integrated bayonet bulb socket for convenient setup

Applications

• Automotive manufacturing
• Assembly lines
• Construction sites

How much power does this beacon need to operate?

This unit needs just 5W of input power to work, making it an energy-efficient signalling solution.

UL E164155

CSA LR108291-1
