SD-1805, Aihara Denki 10VA Autotransformer, 100V ac Primary, 14 V ac, 16 V ac, 18 V ac, 20 V ac Secondary

Transformer, 6 V to 24 V Type

Compound-wound, with seal between first / second winding

Note

All transformers come with plate washer, protective pads and screws, and bolt/washer for attachment via single hole.Always make sure to attach pads above and below the transformer coil, then attach the plate washer above the top pad.Do not screw in the fixing bolt too tightly. Doing so may damage the transformer.Make sure neither side of the fixing bolt makes contact with the metal chassis or frame.Failure to do so may lead to a transformer short and irreparable damage.
Transformers with 2 ´ 24 V outputs are not certified under VDE/SEV.

Standards

UL506 (file E145880)
VDE, SEV, UL, _CUL, VDE 0551 3N 60742
