ZB5AV053, Schneider Electric Orange Pilot Light Head, 22mm Cutout Harmony XB5 Series

Illuminated Head for Pilot Light

Pilot light heads for use with body consisting of either integral LED only or BA9s incandescent bulb, neon, or LED.

The colour of the head should be matched with the same colour of the chosen LED block.

Standards

IEC, JIS

Approvals

UL, CSA

Schneider Electric Push Button Switch, Plastic Housing, 22mm Cutout - Harmony XB5 Series - ZB5AV053

Easily check your machine's operating status with this orange push button switch from Schneider Electric. Designed for use with an LED pilot light, it illuminates when an attached device is switched on. As the unit has a wide operating temperature range between -40°C and +70°C, it's a durable choice for use in harsh conditions. The bezel is housed in durable plastic, which is insulating for shock-free handling and installation.

Features & Benefits

• IP69K rating indicates it's completely protected against dust, water and steam
• Resists shock and vibration, so it holds firm in heavy-duty applications
• Compact external dimensions of 29 (H) x 29 (W) x 31mm (D) mean it uses minimal panel space

Applications

• Manufacturing facilities
• HVAC systems
• Construction equipment
• Chemical plants

What cutout size do I need to install this switch?

It has an industry-standard cutout diameter of 22mm, so you can fit it into an existing slot on your panel.

What colour LED block should I use with this unit?

To boost the clarity of the button, it's advisable to use it with an LED block in the same orange colour.

UL E164353

Datasheet

Harmony Led 2023 Changes EN

New Harmony Leaflet

Product Environmental Profile

Line Drawing - ZB5AV053

Instruction Sheet - ZB4/ZB5 Series
