RS PRO 6 → 10 A Motor Protection Circuit Breaker, Автоматический выключатель

RS PRO 6 → 10 A Motor Protection Circuit Breaker

This motor protection switch from the RS PRO range guards against overloading or failure due to an external conductor. It acts as a circuit breaker when the current being monitored by the device reaches a specific limit. A protection switch is often used on small machines.

You can position this switch horizontally or vertically and it has screw termination. Voltage rated at 690 V, it automatically switches off at a high current with either thermal or magnetic release. It's capable of performing up to 40 circuit breaks per hour and can be reset.

You'll find this type of motor switch in industrial and building applications like chillers, heat pumps and cooling towers. As an RS PRO product, it's been stringently tested so you can have confidence in its consistent quality and performance.

Features and Benefits

• Motor protection switch
• Current range of 6 A to 10 A
• Voltage rating of 690 V
• Length of 80 mm
• Width of 45 mm
• Depth of 73.5 mm
• For use with the MS25 series
• Screw terminal

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

Datasheet
